知慳惜電
| 集成吊頂導光照明系列 | SINLOON® | ||||||||
| Chip-on Ceiling Light Series | 超薄節能導光燈 | ||||||||
| Ultra-thin energy saving guide light | |||||||||
| Data Specification : |  |
 |
|||||||
 |
 |
CT-F303025-12 | |||||||
| Characteristic Parameters: | |||||||||
| 型號 Model: | CT-F303025-12 | ||||||||
| 尺寸 Dimension : | 300*300*15mm | ||||||||
| 發光尺寸 The Emitting Size: | 258*258mm | ||||||||
| 輸入電壓 Input Voltage (High efficiency): | AC110V~240V 50/60Hz | ||||||||
| 輪出電壓 Output Voltage: | 24.8V/DC | ||||||||
| 電流 Current: | 0.3A | ||||||||
| 類型 LED Type: | SMD-4014 | ||||||||
| 數量 LED Quantity: | 35pcs | ||||||||
| 功率 System Power (W): | 8W ±5% (75lm/W) | ||||||||
| 光通亮 LED Flux (lm): | 600lm ±5% | ||||||||
| 燈具效率 Lighting Factor: | 60% | ||||||||
| 色溫 Color Temperature (K) | 3800K ±7%; 6000K ±8% | ||||||||
| 顯色指數 Color Rendering Index: | >80 | ||||||||
| 發光角度 Illumination Angle: | 120o | ||||||||
| 壽命 Lifespan: | 50000hrs | ||||||||
| 環境溫度 Ambient Temperature (℃): | -20℃ ~ 50℃ | ||||||||
| 重量 Weight (Kg): | <1.0/kg | ||||||||
| 認證 Certificate: | CCC, UL, CE, GC, RoHS, FCC, IP55. | ||||||||
| 類別 Others type: | Suspend Ceiling | ||||||||
| * If you have any question which is not in this specification, please contact us. |
|
||||||||
