| SINLOON® | LED 貼片軟燈帶 | Chip Type: 5050 | |||||||
| LED Flexible Strip Light | Power: 7.2W - 28.8W/M | ||||||||
|
- | ||||||||
| Feature: | |||||||||
| LED SMD-5050 Type | LED 軟燈條優點: |  |
- | ||||||
| Banding angle 120o | 適用於潮濕的地方,小功率,低熱量. | ||||||||
| Life span 50,000hrs | 比傳統的照明壽命長達8倍耐用環保. | ||||||||
| Waterproof IP20/IP65/IP66/IP68 | 有不同的發光色彩可供選擇,點綴節日氣氛. | - | - | ||||||
| LED any color for choice | 兼容不同交流電源,低壓直流安全可靠. | ||||||||
| Flexible SMD LED strip with FPT | 防水級別可達 IP68 | ||||||||
| Low voltage DC12/24V safe and reliable | 室內及戶外使用. |  |
|||||||
| Suitable for indoor and outdoor applications. | 每米長度功率由 7.2W-28.8W. | ||||||||
| Characteristics: | |||||||||
| Model No. | LED Q'TY. | Power/M | PCB (L*W) | Voltage | Lumen/ea | Angle | Color | ||
| FSL-5050Q30 | 30 pcs | 7.2W | 1000*10mm | DC12/24V | 14-16lm | 120o | WW/CW/NW/R/G/B/RGB | ||
| FSL-5050Q60 | 60 pcs | 14.4W | 1000*10mm | DC12/24V | 14-16lm | 120o | WW/CW/NW/R/G/B/RGB | ||
| FSL-5050Q90 | 90 pcs | 21.6W | 1000*10mm | DC12/24V | 14-16lm | 120o | WW/CW/NW/R/G/B/RGB | ||
| FSL-5050Q120 | 120 pcs | 28.8W | 1000*15mm | DC12/24V | 14-16lm | 120o | WW/CW/NW/R/G/B/RGB | ||
| Water Proof: | Case pipe filling glue. | Package: | 5M / Reel | ||||||
| * If you have any question which is not is in the specification, please contact us. | - | - |
|||||||
| *在本規格書裡如果您未能找或參數指標未能達到你的應用要求即未在本規格書裡表現出來請與我們聯絡. | |||||||||
