| SINLOON® | 圓型導光板天花燈尺寸系列 | |||
| LED Ceiling Lamp Size - Series | ||||
| Unit: mm | ||||
| 型號 | 尺寸 | 外形尺寸 | 發光尺寸 | 開孔尺寸 |
| 2" | Ø85mm*T10mm | Ø85mm | Ø66mm | Ø72mm |
| 3" | Ø105mm*T10mm | Ø105mm | Ø90mm | Ø95mm |
| 4" | Ø120mm*T10mm | Ø120mm | Ø102mm | Ø105mm |
| 5" | Ø150mm*T10mm | Ø150mm | Ø129mm | Ø135mm |
| 6" | Ø175mm*T10mm | Ø175mm | Ø130mm | Ø160mm |
| 7" | Ø190mm*T10mm | Ø190mm | Ø171mm | Ø175mm |
| 8" | Ø255mm*T10mm | Ø225mm | Ø202mm | Ø210mm |
| 9" | Ø235mm*T10mm | Ø235mm | Ø190mm | Ø222mm |
| 11" | Ø300mm*T10mm | Ø300mm | Ø247mm | Ø285mm |
| 以上尺寸和實物尺寸會有誤差,所以以上的尺寸僅供參考. |  |
|||
| The above information is for reference only. | ||||
 |
- | - | ||
