| Characteristic Parameters: |
Off light (100%) |
|
型號 Model No.:
|
RED-T8-A10209-6K |
| 尺寸 Dimension (Φ*L): Φ/Circular Type |
Φ26*600mm |
| 實際長度 Actual Lenght Size: |
588mm |
| 鋁基板寬度 PCB width : |
7mm |
| 輸入電壓 Input Voltage: |
AC220V~240V 50/60Hz |
| 類型 LED Type: |
SMD2835 |
| 數量 LED Quantity: |
48pcs |
| 功率 System Power (W) |
9W±5% |
| 光通亮 LED Flux (lm) |
900lm ±5% |
| 燈罩 Frost cover |
Translucent |
| 功率系數 Power Factor: |
>0.5 |
| 色溫 Color Temperature (K) |
6000K ±8% |
| 顯色指數 Color Rendering Index: |
>80Ra |
| 驅動方式 Drive mode |
Off light (100%) |
| 發光角度 Illumination Angle: |
320o |
| 燈源壽命 LEDs Lifespan: |
50000hrs |
| 環境溫度 Ambient Temperature (℃): |
-20℃ ~ 50℃ |
| 認證 Certificate: |
CE/EMC |
 |
