| SINLOON® | COB LED 軌道燈 | 型號: 幻影系列 | |||
| COB LED Track Light - Phantom series | |||||
  Data Spec. : COB LED Track Light - Phantom series |
|||||
| 優勢介紹 | |||||
| 設計獨特而小巧 |  |
||||
| 靈活多變的光束角（12°-52°），適合不同的場景 | |||||
| 11種多重顏色任選，展現無限多彩燈姿 | |||||
| 提供 TRIAC 調光選配 | |||||
| 專業的光學設計,使光色分佈均勻,過濾掉光斑和暗光 | |||||
| 可提供4線軌道適配器 | |||||
| Characteristic Parameters: | |||||
| 型號 Model: | WDF-Phantom10W | WDF-Phantom12W | WDF-Phantom15W | WDF-Phantom18W | |
| 功率 System Power (W): | 10W ±2% | 12W ±2% | 15W ±2% | 18W ±2% | |
| 光通亮 LED Flux (lm): | 700-800lm ±5% | 840-960lm ±5% | 1000-1200lm ±5% | 1200-1450lm ±5% | |
| 色溫 Color Temperature (K) | 3000K-6000K | 3000K-6000K | 3000K-6000K | 3000K-6000K | |
| 輸入電壓 Input Voltage (AC): | AC100-240V 50/60Hz | ||||
| 調光選配 Tric Dimmable: | NA/Yes | NA/Yes | NA/Yes | NA/Yes | |
| 類型 Kind of LED: | COB | COB | COB | COB | |
| 數量 COB LED Quantity: | 1 pcs | 1 pcs | 1 pcs | 1 pcs | |
| 光束角 Leam Angle: | 20°-52° | 20°-52° | 20°-52° | 20°-52° | |
| 顯色指數 Color Rendering Index: | >85Ra(90/97Ra Opaional) | ||||
| 功率因數 Power Factor (PF): | >0.85 pf | >0.85 pf | >0.85 pf | >0.85 pf | |
| 壽命 Lifespan: | 30000hrs | 30000hrs | 30000hrs | 30000hrs | |
| 環境溫度 Ambient Temperature (℃): | -25℃ ~ 50℃ | -25℃ ~ 50℃ | -25℃ ~ 50℃ | -25℃ ~ 50℃ | |
| 認證 Certificate: | CE, IP20. | CE, IP20. | CE, IP20. | CE, IP20. | |
| 材質 Housing Material: | Aluminum | Aluminum + Special cooling fan | |||
| 顏色 Housing Color: | White/Black | White/Black | White/Black | White/Black | |
| 尺寸 Lamp Dimension (Φ*H): | Φ50 x 135*87 | Φ50 x 135*87 | Φ50 x 135*87 | Φ50 x 135*87 | |
| 重量 Weight (Kg):/pc | 240g | 240g | 240g | 240g | |
| 電源 Adapter : | 2 wires / 3 wires ( 4 wires 3-Phases Optional ) | ||||
| 保固期 Warranty : | 1 year | 1 year | 1 year | 1 year | |
| ＊在本規格書裡,如果你未能找到或參數指標未能達到你的應用要求,即未在本規格表現出來,請與我們聯絡. | |||||
 |
 |
 |
- | ||
 |
|||||
