T8 LED Tube (Plastic)

T8 LED Tube (Plastic)

環保照明系列

SINLOON® LED 燈管 T8-F 系列 型號類別: T8-F 外殼用料半鋁半塑
LED Tube Conventional Series Classification:T8-F Aluminium Alloy + Plastic
Date Specification: T8 LED Tube  (Aluminium Alloy + Plastic)
■ Feature: LED Tube Figure
Length Dimension: Standard size. 按圖放大
Case material: Aluminum alloy + Plastic
Driver External Driver and Non-isolated
On lighting: Transient to start
Input voltage: AC110~240V  50/60Hz
Light source: LED SMD2835 chip diode
Shine: To product light not flashing
LEDs Lifespan: 35,000hrs
■ Characteristic Parameters:
型號 Model No.: T8-F60-48A-10W T8-F90-72A-14W T8-F120-96A-18W T8-F150-120A-24W
尺寸 Dimension (L*Φ):  Φ/Circular Type 600*26mm 900*26mm 1200*26mm 1500*26mm
實際長度 Actual Length Size: 588mm 894mm 1198mm 1498mm
鋁基板寬度 PCB width : 7mm 7mm 7mm 7mm
輸入電壓 Input Voltage: AC110V~240V  50/60Hz
類型 LED Type: SMD2835 SMD2835 SMD2835 SMD2835
數量 LED Quantity: 48pcs 72pcs 96pcs 120pcs
功率 System Power (W) 10W±1 14W±1 18W±1 24W±1
光通亮 LED Flux (lm)  / 燈罩 Frost cover Transparent Translucent Transparent Translucent Transparent Translucent Transparent Translucent
1000lm ±5% 950lm ±5% 1400lm ±5% 1350lm ±5% 1800lm ±5% 1750lm ±5% 2400lm ±5% 2300lm ±5%
功率系數 Power Factor: >0.95 >0.95 >0.95 >0.95
色溫 Color Temperature (K) 2800K ±7% / 6500K ±8% 2800K ±7% / 6500K ±8% 2800K ±7% / 6500K ±8% 2800K ±7% / 6500K ±8%
顯色指數 Color Rendering Index: >80Ra >80Ra >80Ra >80Ra
發光角度 Illumination Angle: 120o 120o 120o 120o
燈源壽命 LEDs Lifespan: 50000hrs 50000hrs 50000hrs 50000hrs
環境溫度 Ambient Temperature (℃): -20℃ ~ 50℃ -20℃ ~ 50℃ -20℃ ~ 50℃ -20℃ ~ 50℃
認證 Certificate: CE,RoHS, CQC, UL,IP20.
■ Superiority (優勢):
● 採用台灣高亮度LED芯片光源,抗震,耐衝擊.
Using high brightness LED chip imported from Taiwan Shock and impact resistant.
● 無熱輻射,安全穏定,可靠,使用壽命長,款式新穎.
No thermal radiation, security and stability, reliable, long life and fashionable style.
● 響應快,無頻閃,眩光小,點亮後瞬間達到全光通量輸出.
Fast response, No flash, Low glare, Lightening instantly reach the luminous flux output.
● 採用優質擴光罩,光色柔和,出光率高
Use the high quality frosted PC, Soft light and the high light extracting Rate.
● 節能高效,比熒光燈節能70%.
High efficiency and energy saving, Saved more than 70% power compare with conventional fluorescent light.
*在本規格書裡如果您未能找或參數指標未能達到你的應用要求即未在本規格書裡表現出來請與我們聯絡.
