Zero Ohm and Jumper Wire (零歐姆及跳線)

PDF File Zero Ohm and Jumper Wire (零歐姆及跳線)

RESISTORS With Iron Body HIGH CURRENT CAPABILITY
SIMILAR TO A 1/4W SIZE RESISTORS (1/6W SIZE ALSO AVAILABLE,
TYPICAL RESISTANCE) IDEAL FOR AUTOMATIC INSERTION OR CUT AND FOR EXCELLENT FOR JUMPER、
BETTER THAN FILM TYPE ZERO OHM Resistors Ceramic Body With Metal Film
LOW RESISTANCE 0.02Ω
SIMILAR TO A 1/4W SIZE RESISTORS (1/6W, 1/2W, 1W and 2W SIZE ALSO AVAILABLE, TYPICAL RESISTANCE)
IDEAL FOR AUTOMATIC INSERTION OR CUT AND FORM

Dimensions							SINLOON®
STYLE			DIMENSIONS(mm)				ZO-IB Figure (外型)
Standard Size	Small Size		L	D	H	d
ZO-IB 1/8W	ZO-IB 1/4WS		3.3±0.4	1.8±0.3	29±2	0.48±0.03
ZO-IB 1/4W	ZO-IB 1/2WS		6.3±0.5	2.3±0.3	28±2	0.58±0.03
ZO-IB 1/2W			9.0±0.5	3.2±0.5	26±2.0	0.65±0.03
ZO-IB 0207⁽¹⁾			9.0±0.5	3.2±0.5	26±2.0	0.65±0.03
ZO-IB 1W			11.5±1.0	4.5±0.5	35±2.0	0.78±0.03
ZO-IB 2W			15.5±1.0	5.0±0.5	32±2.0	0.78±0.03
1. Melf Zero Ohm Resistor 0.5W

Dimensions
STYLE			DIMENSIONS(mm)				ZO-CB Figure (外型)
Standard Size	Small Size		L	D	H	d
ZO-CB 1/8W	ZO-CB 1/4WS		3.3±0.4	1.8±0.3	29±2	0.48±0.03
ZO-CB 1/4W	ZO-CB 1/2WS		6.3±0.5	2.3±0.3	28±2	0.58±0.03
ZO-CB 1/2W			9.0±0.5	3.2±0.5	26±2.0	0.65±0.03
ZO-CB 0207⁽¹⁾			9.0±0.5	3.2±0.5	26±2.0	0.65±0.03
ZO-CB 1W			11.5±1.0	4.5±0.5	35±2.0	0.78±0.03
ZO-CB 2W			15.5±1.0	5.0±0.5	32±2.0	0.78±0.03
1. Melf Zero Ohm Resistor 0.5W

□ SPECIFICATION
STYLE		ZO-IB				ZO-CB
		Resistors With Iron Body				Resistors Ceramic Body With Metal Film
Max. Resistance		Less than 0.005Ω				Less Than 0.02Ω
Body Material		Iron with tin-plated				Ceramic Body With Metal Film
Lead Material		Tinned copper				Tinned Copper
Marking		Color code by one black band				Color Code by one black band
Insulation Resistance		Dry/10.000MΩ. Wet/100MΩ				Dry/10.000MΩ. Wet/100MΩ
Dielectric Withstanding Voltage		Atmospheric/500V RMS				Atmospheric/500V RMS
		Reduced/325V RMS				Reduced/325V RMS
Current Rating		15 AMPS at 75℃ for 1/4W.				3 AMPS at 75℃ for 1/6W.
		10 AMPS at 75℃ for 1/6W.				5 AMPS at 75℃ for 1/4W.
						7 AMPS at 75℃ for 1/2W.
						8 AMPS at 75℃ for 0.6W
						9 AMPS at 75℃ for 1W.
						11 AMPS at 75℃ for 2W.
Packing		5000pcs per Tape Box				5000pcs per Tape Box.
零歐姆電阻器及跳線是用來聯接 P.C. 板上的兩點線路而設計。
可應用於：
(1) 聯接 P.C.板上兩條線路。
(2) 電路設計變更，接點的增减聯接。
(3) 改變電路接點的連接。適用於自動插件。
