Temperature Compensated Crystal Oscillator Series
| 溫度補償晶體振蕩器系列 | SINLOON® | ||
| Temperature Compensated Crystal Oscillator Series | |||
  Data Spec.: TCXO - SMD1612-JT1S |
|||
 |
|||
| 4 Pad Version 1.6×1.2 mm | |||
| Temperature Stability: ± 0.5 ppm ~ ± 2.0 ppm. | |||
| Supply voltage range: 1.8V ~ 3.3V. | |||
| Voltage Control Function Available. | |||
| RoHS Compliant /Pb Free. | |||
| ■ Standard Specification | |||
| PARAMETERS | Sign | SPECIFICATION | |
| Frequency Range | F0 | 26 ~ 52MHz | |
| Oscillation Mode | Fundamental | ||
| Supply voltage | Vdd | 1.8V~3.3V | |
| Frequency Tolerance | FT | ±1.0ppm、±1.5ppm、±2.0ppm | |
| Frequency Stability | FS | ±25ppm, ±50ppm, or specify | |
| Vs Temperature (ref. to +25℃) | ±0.5 ~ ±2.0ppm | ||
| Vs Supply voltage change (±5%) | ±0.2ppm | ||
| Vs Load change (±10%) | ±0.2ppm | ||
| Input Current | Idd | 2mA max. | |
| Output Load | 10KΩ//10pF | ||
| Operating Temp. Range: | TOPR | -30～+85℃ , -40～+85℃ | |
| Storage Temp. Range: | TSTG | -55～+125℃ | |
| Start-up time | 5ms max. | ||
| Harmonics | -5dBc max. | ||
| Phase Noise @1KHz offset | -130 dBc/Hz max | ||
| Aging (at 25℃) | ±1ppm/year max. | ||
| ☉All specification subject change without notice. |  |
||
