| SINLOON® | Frequency Control Products | |
| 石英晶體諧振器 | ||
  DIP KHz Crystal Resonators: DT26-JXD6 (2Pin 2060) |
||
 |
||
| ● 2 PIN Version 2.0×6.0 mm | ||
| ● 32.768 KHz standard | ||
| ● ±5 ppm type available | ||
| ● Excellent Reliability Performance | ||
| ● RoHS Compliant /Pb Free. | ||
| ■ Standard Specification | ||
| PARAMETERS | Symbol | SPECIFICATION |
| Nominal Frequency | F0 | 32.768KHz (30~ 200KHz available) |
| Frequency Tolerance | FL | ±5ppm, ±10ppm, ±20ppm |
| Turnover Temperature | Ti | +25℃±5℃ |
| Parabolic Coefficient | B | (-0.030±10%)×10-6/℃2 |
| Loading Capacitance | CL | 6.0pF, 7.0pF, 9.0pF, 12.5pF |
| Equivalent Resistance | ESR | 40KΩ max. |
| Drive Level | DL | 0.1μW typ.（0.5μW max.） |
| Shunt Capacitance | C0 | 1.65pF typ. |
| Frequency Ageing | FAGE | ±3ppm （+25℃±3℃, First Year） |
| Operating Temp. Range: | TOPR | -40～+85℃ |
| Storage Temp. Range: | TSTG | -40～+85℃ |
| ☉All specification subject change without notice. | ||
 |
||
