Crystal Resonators MHz Series
| SINLOON® | Frequency Control Products | |
| 石英晶體諧振器 | ||
  SMD Crystal Resonators - SMD2520-JX2A |
||
 |
||
| ● 4 Pad Version 2.5×2.0 mm | ||
| ● High precision and high frequency stability | ||
| ● Excellent heat resistance and environmental | ||
| characteristics | ||
| ● EMI shielding possible by grounded lid | ||
| ● RoHS Compliant /Pb Free | ||
| ■ Standard Specification | ||
| PARAMETERS | Sign | SPECIFICATION |
| Frequency Range | F0 | 12～66MHz |
| Oscillation Mode | Fundamental | |
| Loading Capacitance | CL | 6pF to 32pF / Series available |
| Drive Level | DL | 10μW（100μW Max） |
| Frequency Tolerance | FL | ±10ppm, ±15ppm, ±20ppm, or specify |
| Equivalent Resistance | RR | See Below |
| Frequency Stability | TC | ±10ppm, ±15ppm, ±20ppm, ±30ppm, or specify |
| Operating Temp. Range: | TOPR | -10～+60℃ to -40～+125℃ |
| Storage Temp. Range: | TSTG | -55～+125℃ |
| ☉All specification subject change without notice. | ||
 |
||
-
