Cement Resistor With Thermal Cut-Offs - CMO
CMO 溫度保險絲是一種不可復位型熱敏保護器件，
用于家用電器及工業設備(電阻、電感電路)的過熱保護，當 CMO 電阻 溫度升高到某不正常程度時，CMO 將電路切斷。
它的全密封結構確保其熔斷系統穩定,可靠，不受外界潮濕等惡劣環境影響 和 傳統 溫度保險絲感測環境溫度狀態的特性不同.
Thermal Cut-offs include Metal Oxide type and wire wound type, cement Resistor with Thermal Cut-offs is specially sharp fusing characteristics .
low cost ,excellent anti-surge characteristics. Applications are widely used in Switching regulators, Video adapters or safety circuit in electrical equipment, etc..
| ENVIRONMENTAL CHARACTERISTICS | SINLOON® | ||||||
| Fusing Temperature Protector | |||||||
| Mark Code | Fusing | Standard | Rated Power at 25℃ | Resistance | |||
| Temp.(℃) | Current | Voltage | 5M | 7M | 10M | Range (Ω) | |
| 113 | 109±2 | 10A | 250V | 1.2W | 1.4W | 2W | 1R ~ 100Ω |
| 133 | 129±2 | 1.6W | 2W | 2.5W | |||
| 157 | 152±2 | 1.6W | 2W | 2.5W | |||
| 192 | 188±2 | 2W | 2.4W | 3.5W | |||
| 227 | 226±2 | 2W | 2.4W | 3.5W | |||
| 102 | 98±2 | 2A | 250V | 0.8W | 1.2W | --- | 1R-100Ω |
| 115 | 110±2 | 1.2W | 1.4W | ||||
| 134 | 129±4 | 1.4W | 1.6W | ||||
| 139 | 135±3 | 1.6W | 2W | ||||
| 145 | 141±2 | 2.1W | 2.4W | ||||
 |
|||||||
